Ableiter mit Wärmerückgewinnung

Druck: 46 bar
Durchsatz: 0 kg/h - 740 kg/h
Temperatur: 300 °C

The DT40/2 thermodynamic disc steam traps are compact and lightweight, easy to install traps, excellent for high pressure systems and steam tracing applications. The insulation cover ensures a consistent operation and makes it particularly ...

Druck: 42 bar
Durchsatz: 0 kg/h - 1.040 kg/h
Temperatur: 300 °C

The DT42/2 thermodynamic disc steam traps are compact and lightweight-easy to install traps, excellent for high pressure systems, including steam tracing applications. These traps have only one moving part and offer a wide operating ...

Druck: 46 bar
Durchsatz: 0 kg/h - 800 kg/h
Temperatur: 400 °C

The DT46 thermodynamic disc steam traps are compact and lightweight, easy to install traps, excellent for high pressure systems and steam tracing applications. The insulation cover ensures a consistent operation and makes it particularly ...

Druck: 0 bar - 14 bar
Durchsatz: 0 kg/h - 7.300 kg/h
Temperatur: 250 °C

The FLT27 is a range of float and thermostatic steam traps with integral air vent designed for modulating discharge of condensate, ensuring maximum system heat transfer. Typical applications include unit heaters, heat exchangers, dryers, ...

Druck: 0 bar - 14 bar
Durchsatz: 0 kg/h - 1.670 kg/h
Temperatur: 198 °C

The IB12/IBB12 is a series of general purpose robust and versatile inverted bucket steam traps manufactured in SG iron. These steam traps operate intermittently and are suitable for use with saturated or superheated steam. Typical applications ...

Druck: 0 bar - 17 bar
Durchsatz: 0 kg/h - 3.700 kg/h
Temperatur: 400 °C

The IB30S/IB30SS is a series of general purpose robust and versatile inverted bucket steam traps manufactured in stainless steel. These steam traps operate intermittently and are suitable for use with saturated or superheated steam. Typical ...

Druck: 5, 10, 15, 27 bar
Durchsatz: 0 kg/h - 610 kg/h
Temperatur: 400 °C

The IB36S/IB36i is a series of robust and versatile inverted bucket steam traps manufactured in carbon steel/stainless steel. These steam traps operate intermittently, and are suitable for use with low to high pressure saturated or superheated ...

Druck: 0 bar - 17 bar
Durchsatz: 0 kg/h - 1.850 kg/h
Temperatur: 250 °C

The BM20 series bimetallic steam traps and air vents are simple and robust traps, recommended for steam process applications where condensate sensible heat can be recovered, steam tracing lines, drip points, storage tank coils, steam ...

Druck: 0 bar - 17 bar
Durchsatz: 0 kg/h - 1.840 kg/h
Temperatur: 250 °C

The BM20R series bimetallic steam traps and air vents are simple and robust traps, recommended for steam process applications where condensate sensible heat can be recovered, steam tracing lines, drip points, storage tank coils, steam ...

Druck: 0 bar - 24 bar
Durchsatz: 0 kg/h - 9.000 kg/h
Temperatur: 250 °C

The BM24 series bimetallic steam traps and air vents are simple and robust traps, recommended for steam process applications where condensate sensible heat can be recovered, steam tracing lines, drip points, storage tank coils, steam ...
